Graves' Disease and Hyperthyroidism

Summary

• Hyperthyroidism is a clinical state of excess thyroid hormone action; Graves' disease, an autoimmune disorder in which TSH-receptor antibodies stimulate the thyroid, is its commonest cause, followed by toxic multinodular goitre (Plummer's disease) and solitary toxic adenoma [1][2][3].
• The worldwide prevalence of hyperthyroidism is approximately 2.5%, with Graves' disease incidence around 30 per 100,000 persons per year, an 8:1 female-to-male ratio, and typical presentation between 20 and 40 years of age [1].
• Management options are antithyroid drugs, radioactive iodine and thyroidectomy, each with situation-specific indications; the three commonest causes are all conditions in which thyroidectomy plays an important, if not primary, role [1][4].

Definition

• Thyrotoxicosis is retained as a term because hyperthyroidism (symptoms from raised circulating thyroid hormone) does not account for all manifestations of the disease; clinical types are diffuse toxic goitre (Graves' disease), toxic nodular goitre, toxic nodule, and rarer causes [4].
• Hyperthyroidism is defined as a clinical state of elevated thyroid hormone action in tissues, usually because of inappropriately high constitutive secretion of thyroid hormone from the thyroid, divided into overt (suppressed TSH with elevated free T4 or T3) and subclinical (suppressed TSH with normal free T4 and T3) [1].
• Graves' disease is an autoimmune disease characterised by constitutive activation of the TSH receptor by TSH-receptor antibodies (TRAb), producing increased thyroid hormone synthesis and secretion [1].

Browse's draws the distinction that makes the classification usable: thyrotoxicosis is the clinical syndrome resulting from exposure to elevated circulating levels of thyroid hormones, while hyperthyroidism refers specifically to thyrotoxicosis arising from overproduction of thyroid hormones by thyroid follicular cells [6]. That matters because a substantial minority of thyrotoxic patients are not overproducing at all, they are releasing preformed hormone from a destroyed gland, and neither antithyroid drugs nor radioiodine will help them.

Causes of thyrotoxicosis

• Table reformats the causes of thyrotoxicosis with their relative frequencies [6].
• Ninety-five per cent are accounted for by the first three causes [6].
• Sabiston classifies the same list by a different and operationally more useful axis, radioiodine uptake.
• Normal or elevated uptake occurs in Graves' disease, toxic multinodular goitre, toxic adenoma, trophoblastic disease, TSH-producing pituitary adenoma and thyroid hormone resistance; no or minimal uptake occurs in painless thyroiditis, amiodarone-induced thyroiditis, subacute thyroiditis, iatrogenic thyrotoxicosis, struma ovarii, acute thyroiditis, follicular thyroid cancer metastases and palpation thyroiditis [1].

Pathophysiology

• In Graves' disease, the whole functioning thyroid is involved, and hypertrophy and hyperplasia are due to abnormal TSH-receptor antibodies binding TSH receptor sites, producing a disproportionate and prolonged effect; 55% of patients have a family history of autoimmune endocrine disease [4].
• Stimulatory antibodies to the TSH receptor are present in the sera of 90% of patients and cause unregulated overproduction of thyroid hormone [6].
• Because of its autoimmune aetiology, Graves' disease can produce extrathyroidal manifestations: Graves orbitopathy occurs in up to 25–30% of patients through autoimmune reactions in orbital and periorbital soft tissue causing proptosis, eyelid retraction, chemosis, periorbital oedema and diminished ocular motility, which if untreated can cause vision loss from corneal lesions or optic nerve compression.
• Skin manifestations include pretibial myxoedema and acropachy, which is oedema at the digits [1].
• Browse's lists four extrathyroidal manifestations: eye disease (ophthalmopathy), skin disease (pretibial myxoedema), acropachy (clubbing), and lymphoid hyperplasia [6].
• Associated autoimmune conditions include Hashimoto thyroiditis, lupus, rheumatoid arthritis, pernicious anaemia and Addison disease [1].

Why the symptoms are what they are

• T3 and T4 have three effects: they increase the metabolic rate of all cells, they increase the sensitivity of β-adrenergic receptors, and they stimulate all cells to grow, though the growth effect is only significant before natural growth has finished [6].
• Increased tissue metabolism therefore causes increased appetite, weight loss and increased heat production; increased adrenergic receptor sensitivity causes tachycardia, extrasystoles, atrial fibrillation, tremor, nervousness, lid retraction and lid lag; and growth stimulation in childhood produces early maturation and a slight increase in growth rate [6].
• In hypothyroidism all of these are reversed, and lack of growth stimulation in a child causes short stature and impaired mental development [6].

The eye signs

• Lid retraction and lag occur in any cause of thyrotoxicosis: sensitisation of sympathetic nerves carried via the third cranial nerve causes overactivity of the involuntary smooth-muscle part of levator palpebrae superioris [6].
• Exophthalmos, ophthalmoplegia and chemosis are the signs specific to Graves' disease, and are present in 30% of Graves' patients [6].
• Graves' ophthalmopathy is thought to result from an immune response to retro-orbital antigens similar to those in the thyroid, or from cross-reactivity of TRAb with TSH receptors present on fibroblasts and adipocytes in the retro-ocular tissues, with the resulting inflammation, oedema and fibrosis affecting retro-orbital tissue and ocular muscles.
• There is an association with smoking, in both frequency and severity of symptoms [6].

Each sign has a mechanism worth knowing. Lid retraction is present when the upper eyelid sits higher than normal (normally midway between the pupil and the superior limbus of the iris) with the lower lid in its correct position; lid lag is present when the upper lid does not keep pace with the eyeball as it follows a finger moving downwards [6]. Exophthalmos is a change in the relationship of the lids to the iris because the eyeball is pushed forwards by an increase in retro-orbital fat, oedema and cellular infiltration, so that sclera becomes visible below the inferior limbus. It makes convergence difficult and allows the patient to look up without raising the eyebrows or wrinkling the forehead, and severe cases can be complicated by corneal ulceration [6]. Ophthalmoplegia results from oedema and cellular infiltration of the ocular muscles, most often superior rectus and inferior oblique, which normally turn the eye up and out, so 'up and out' is the first movement to weaken [6]. Chemosis is oedema of the conjunctiva caused by obstruction of its venous and lymphatic drainage by increased retro-orbital pressure; the normal conjunctiva is smooth and invisible, so a thickened, crinkled, slightly opaque conjunctiva is easy to recognise [6]. Pretibial myxoedema is a violaceous, non-pitting induration of pretibial skin occurring in 1–5% of patients with Graves' disease, with skin biopsy showing mucin in the lower dermis and overlying hyperkeratosis [6].

Toxic nodular disease

• Toxic nodular goitre (Plummer's disease) results from autonomously functioning nodules arising from TSH-receptor gene mutations causing constitutive hormone synthesis, typically in a simple nodular goitre present long before hyperthyroidism develops (secondary thyrotoxicosis), usually in the middle-aged or elderly and rarely with eye signs [1][4].
• These 'warm' or 'hot' nodules are rarely malignant and typically do not require biopsy, but they can coexist with non-functioning nodules in the same gland which must be evaluated independently [1].
• A toxic solitary nodule is autonomous and not driven by TRAb; TSH is suppressed by high circulating hormone, and the surrounding normal thyroid tissue is itself suppressed and inactive [4].
• A toxic adenoma affects females at a median age of 50 to 60 years with a mild female predominance, and the main theory of its pathogenesis is constitutively activating TSH-receptor gene mutations, although the prevalence of these mutations is not universal and varies widely by geography [1].
• Histologically, hyperthyroidism shows hyperplasia of acini lined by high columnar epithelium, many empty, others with vacuolated colloid showing a characteristic 'scalloped' pattern [4].

Amiodarone-induced thyrotoxicosis

• Amiodarone is an iodine-rich compound structurally similar to T4, containing 37% iodine by molecular weight; a normal dosing schedule delivers over 100 times the daily dietary iodine requirement, and amiodarone-induced thyrotoxicosis occurs in up to 6% of patients taking it [1].
• Two distinct mechanisms exist. Type 1 is caused by the Jod-Basedow phenomenon, in which the high iodine load potentiates excess thyroid hormone synthesis and release, and is more common in patients with pre-existing hyperthyroid disease. Type 2 usually occurs in patients with no pre-existing thyroid disease and is a destructive thyroiditis from direct drug toxicity on follicular cells, releasing preformed hormone.
• Mixed forms occur [1].

Susceptibility genes and the gland's histology in Schwartz's account

• First described by the Welsh physician Caleb Parry in a posthumous article of 1825 and named after Robert Graves' three patients of 1835, Graves' disease causes 60–80% of hyperthyroidism in North America, with a 5:1 female preponderance and peak incidence at 40–60 years; suggested triggers are the postpartum state, iodine excess, lithium and bacterial or viral infection [7].
• Haplotyping links it to HLA-B8, HLA-DR3 and HLA-DQA10501 in white patients while HLA-DRB10701 is protective, and susceptibility genes include CTLA-4, CD40 (whose upregulation lowers the threshold for B-cell activation and enhances IL-6 secretion and T-cell activation within thyrocytes), PTPN22 (lymphoid tyrosine phosphatase) and CD25 (IL-2 receptor α-chain); sensitised T-helper cells then drive B cells to produce TSH-receptor antibodies, both stimulating immunoglobulins and TSH-binding inhibiting immunoglobulins [7].
• Macroscopically the gland is diffusely and smoothly enlarged and hypervascular; microscopically it is hyperplastic with columnar epithelium, minimal colloid, mitotic nuclei, papillary projections of hyperplastic epithelium and lymphoid aggregates [7].
• Orbital fibroblasts and muscle are thought to share the TSH receptor as antigen, with ophthalmopathy resulting from cytokines released by sensitised killer T cells and cytotoxic antibodies; upward and lateral gaze are limited by involvement of the inferior and medial rectus respectively [7].

Clinical features

• Multisystem manifestations include neurological (tremor, anxiety, restlessness, emotional lability, insomnia), gastrointestinal (diarrhoea, increased appetite, weight loss), cardiac (palpitations, sinus tachycardia or atrial fibrillation, dyspnoea, chest pain), dermatological (thin hair, pretibial myxoedema or acropachy, erythema), reproductive (menstrual irregularity, reduced libido), goitre (diffuse or nodular, bruit), and constitutional features (heat intolerance, muscle weakness) [3].
• Uncontrolled hyperthyroidism can rarely cause severe cardiovascular complications including cardiomyopathy and congestive heart failure that can progress to cardiovascular collapse and death [1].
• Symptoms found only in Graves' disease include exophthalmos and pretibial oedema [2].

• Browse's organises the history by system, and notes that neurological symptoms such as nervousness, irritability, insomnia, depression and excitement may be noticed by family long before the patient is aware of them [6].
• Metabolic symptoms are increased appetite with weight loss or absence of weight gain, feeling hot with a preference for cold weather and dislike of warm, and excessive sweating; cardiovascular symptoms are palpitations, exertional breathlessness, ankle swelling and chest pain; alimentary symptoms are a change of bowel habit, usually diarrhoea; genital tract symptoms are oligomenorrhoea or amenorrhoea; and musculoskeletal symptoms include proximal myopathy with wasting and weakness of the small muscles of hand, shoulder and face in addition to generalised weight loss [6].
• Hyperaesthesia, headaches, vertigo, and tremors of the hands and tongue may occur, and a thyrotoxic psychosis may be present [6].

Examination

• Feel the pulse: tachycardia suggests thyrotoxicosis, bradycardia hypothyroidism, and thyrotoxicosis may cause atrial fibrillation, which may be the only sign in elderly patients [6].
• Are the palms moist and sweaty? Test for tremor by asking the patient to hold the arms out in front with elbows and wrists straight and fingers straight and separated.
• Thyrotoxicosis causes a fine, fast tremor, and if in doubt hold out your own hand beside the patient's for comparison, or accentuate it by placing a sheet of paper over the fingers [6].
• A similar tremor may be present in the protruded tongue [6].
• Tachycardia is usually over 90 beats per minute, and the pulse is irregular if there are extrasystoles or atrial fibrillation; with mild heart failure there may be basal crackles and ankle oedema [6].

• In the neck, the gland is usually enlarged, but hyperthyroidism can be present without significant enlargement; the enlargement may be diffuse, nodular or tender depending on the pathology, and a diffusely enlarged hyperaemic gland usually has a systolic bruit audible over its lateral lobes [6].
• Patients with thyrotoxicosis show generalised weight loss, especially about the face, sometimes with localised wasting of hands, face and shoulder muscles; they may look hot and be sweating even in a cold room, and they look worried and nervous and move in an agitated, jerky way [6].
• Distended neck veins from thoracic-inlet obstruction may show Pemberton's sign, facial redness on raising both arms above the head [6].
• Rarely, patients present with life-threatening thyrotoxic crisis, 'thyroid storm', precipitated by a variety of triggers [3].

Distinguishing the three common causes at the bedside

Table reformats the distinguishing features of the three commonest causes of thyrotoxicosis [1][6].

Signs Schwartz names

Dermopathy occurs in only 1–2% and consists of glycosaminoglycan deposition thickening the pretibial skin and dorsum of the foot; lid lag is von Graefe's sign and upper-lid spasm exposing sclera above the limbus is Dalrymple's sign, both with the stare reflecting catecholamine excess rather than infiltration; onycholysis is common, gynaecomastia is common in young men, acropachy denotes rare subperiosteal new bone and metacarpal swelling, black patients often note skin darkening, cutaneous vasodilatation widens the pulse pressure to give a collapsing pulse, and the enlarged pyramidal lobe is evidence of diffuse symmetric enlargement, sometimes with a bruit or thrill and a loud supraclavicular venous hum [7]. Toxic adenomas usually reach at least 3 cm before causing hyperthyroidism and present in younger patients as recent growth of a long-standing nodule with no palpable contralateral tissue, whereas toxic multinodular goitre may first declare itself when a patient is started on low-dose suppression for the goitre, or present only as T3 toxicosis, atrial fibrillation or heart failure [7].

Etiology

• Graves' disease is caused by IgG antibodies to the TSH receptor (long-acting thyroid stimulator, thyroid-stimulating immunoglobulin) and is the most common cause of hyperthyroidism, at about 75–80% [1][2].
• Toxic multinodular goitre is the second most common cause in the United States and the most common cause among the elderly and in iodine-deficient regions, with a 5:1 female-to-male ratio, typically affecting adults over 50 [1].
• A single toxic nodule occurs more often in younger women and needs to be over 3 cm to become symptomatic, functioning autonomously; 20% of hot nodules eventually cause symptoms [2].
• Long-standing multinodular goitres can develop secondary thyrotoxicosis in the elderly, sometimes triggered by administration of iodine-containing contrast in medical imaging [6].
• Rarer causes include drug-induced thyrotoxicosis (amiodarone, lithium, tyrosine kinase inhibitors, antiretrovirals), TSH-secreting pituitary adenoma, β-HCG-mediated hyperthyroidism (gestational, hydatidiform mole), thyroid cancer, subacute and postpartum thyroiditis from release of preformed hormone, and factitious ingestion of excess thyroid hormone [2][3].
• Trophoblastic tumours and TSH-secreting pituitary tumours are rare causes [2].

Diagnosis

• Initial evaluation includes history and examination for thyrotoxicosis-related comorbidities and biochemical tests: TSH with free T4 and T3, TRAb for Graves' disease, and TPO antibodies for Hashitoxicosis [3].
• The 2016 ATA guidelines for hyperthyroidism recommend initial evaluation of thyrotoxicosis with TRAb measurement, radioactive iodine uptake, or thyroidal blood flow on ultrasonography; Graves-related thyrotoxicosis shows elevated TRAb, elevated iodine uptake and/or elevated thyroidal blood flow [1].
• TRAb is present in up to 90% of Graves' disease patients and is diagnostic when positive [1].
• Sonographic features of Graves' disease include a diffusely hypervascular gland, often with heterogeneous echogenicity, and thyroid nodular disease may also be identified.
• Nuclear scintigraphy with technetium-99m pertechnetate or iodine-123 helps differentiate TSI-negative Graves' disease from toxic nodular disease on the basis of a diffuse rather than nodular uptake pattern, and cross-sectional imaging of the head may be useful for evaluating orbitopathy [1].
• Diagnosis of Graves' disease in a thyrotoxic patient with goitre is supported by low TSH, high T3/T4, LATS level, and diffuse iodine-123 uptake on thyroid scan [2].

• For toxic multinodular goitre, thyroid function tests are mandatory, a survey of thyroid antibodies including TRAb is necessary to identify coexisting autoimmune thyroiditis and rule out Graves' disease, nuclear scintigraphy is the first-line imaging study and identifies the location and distribution of autonomously functioning nodules, and ultrasound is highly recommended as a correlative study to assess overall thyroid size and characterise any non-functioning nodules that may require biopsy [1].
• Toxic adenoma shares most of the diagnostic approach of toxic multinodular goitre; the ATA guidelines in fact combine the two groups in their treatment recommendations [1].
• Changes in hormone activity can be assessed by clinical examination, by measuring TSH, free T3 and T4, and by measuring the rate, quantity and pattern of uptake of radio-labelled technetium or iodine [6].

Schwartz's diagnostic sequence

• When eye signs are present no further test is generally needed; without them an ¹²³I uptake and scan showing raised uptake in a diffusely enlarged gland confirms Graves' disease, technetium pertechnetate (trapped but not organified) gives lower normal uptake and higher background but less whole-body radiation, free T3 is checked when free T4 is normal because early Graves' and toxic nodules may show T3 toxicosis, anti-Tg and anti-TPO antibodies are raised in up to 75% but are non-specific, and TSH-receptor or thyroid-stimulating antibodies are diagnostic and raised in about 90% [7].
• Conditions with raised uptake (Graves', toxic multinodular goitre, toxic adenoma, amiodarone or iodine, thyroid cancer, struma ovarii, hydatidiform mole, TSH-secreting adenoma) are distinguished from those releasing preformed hormone with low uptake, acute-phase Hashimoto's, subacute thyroiditis, factitious thyrotoxicosis and "hamburger thyrotoxicosis" [7].
• Toxic adenomas carry somatic TSH-receptor mutations and sometimes gsp mutations, and end-organ resistance to T4 (Refetoff's syndrome) raises T4 with a usually normal TSH [7].

Scoring and Severity

Hyperthyroidism severity is biochemically divided into overt disease (suppressed TSH with elevated free T4 or T3) and subclinical disease (suppressed TSH with normal free T4/T3), with subclinical disease generally milder in presentation, though both can cause clinically significant symptoms [1]. The 2016 ATA guidelines provide an evidence-based table of clinical situations favouring one modality over another for Graves' hyperthyroidism [1]:

Table reformats the 2016 ATA table of clinical situations favouring a particular modality for Graves' hyperthyroidism [1].

Browse's correlation table is the corresponding bedside tool, mapping the clinical state of the gland against its endocrine function to produce a differential diagnosis: a diffusely enlarged hyperthyroid gland is Graves' disease; multinodular enlargement with hyperthyroidism is toxic multinodular goitre (Plummer's syndrome); a solitary nodule with hyperthyroidism is an autonomous toxic nodule; and a hyperthyroid patient with no palpable goitre has either Graves' disease or thyroxine overdose [6].

Treatment and Management

• Non-specific measures such as rest and sedation are used only alongside specific treatment: antithyroid drugs, surgery and radioiodine [4].
• Antithyroid drugs (carbimazole, propylthiouracil) restore and maintain a euthyroid state in the hope of permanent remission but cannot cure a toxic nodule, where recurrence is certain on stopping; failure rate is at least 55%, with treatment duration tailored from 6 months in mild disease to 2 years in severe [4].
• Methimazole is the preferred antithyroid drug over propylthiouracil, except in pregnancy, because PTU was found to be more often associated with liver failure requiring transplantation; methimazole crosses the placenta and can cause cretinism in newborns, so PTU is used in pregnancy [1][2].
• Beta-blockers such as propranolol 40–120 mg/day control tachycardia and tremor and inhibit peripheral T4-to-T3 conversion [3][4].
• Hormone secretion can be suppressed pharmacologically in several ways: high-dose iodine transiently inhibits hormone release (the Wolff-Chaikoff effect); potassium perchlorate interferes with iodine trapping; and carbimazole and propylthiouracil inhibit the iodination of tyrosine and the coupling of tyrosines to make thyronines [6].

• Radioactive iodine reduces functioning thyroid mass below a critical level; it is contraindicated in active Graves ophthalmopathy, which it may worsen, in pregnancy because it is teratogenic, and around young children [3].
• In the US, radioiodine is the most commonly employed treatment for Graves' disease, though antithyroid medication is increasingly used first-line, with nearly one-third of patients achieving long-term remission on medication alone [1].
• Although radioiodine ablation is often billed as extremely low-risk or no-risk, emerging evidence suggests a higher rate of secondary malignancy than previously reported [1].
• Thyroidectomy is generally preferred for severe eye disease, failure or contraindication of other treatments, need or desire for rapid reversal of hyperthyroidism, coexisting suspicious nodules, large compressive goitres, and pregnancy or breastfeeding; although it is a first-line option, in practice it is often relegated to a secondary role because of perceived risks associated with general anaesthesia and surgery [1].
• Indications for surgery also include a non-compliant patient, recurrence after medical therapy, children, pregnant women uncontrolled on PTU, or a concomitant suspicious thyroid nodule, the last being the most common indication [2].
• Near-total or total thyroidectomy is preferred for Graves' disease when radioactive iodine is contraindicated, when the goitre is large (over 80 g) or airway obstruction appears imminent, or in patients with demonstrated poor compliance with or tolerance of antithyroid medication [9].

Treatment differences in toxic nodular disease

• The same three options apply to toxic multinodular goitre but with three differences [1].
• First, antithyroid medication is generally not advocated as a long-term strategy except where the other two are absolutely contraindicated, such as in elderly, ill or frail patients with limited life expectancy, because the disease is not autoimmune and autonomous nodules do not undergo remission with medical therapy.
• Second, radioiodine is the most common definitive treatment in the US, but the dose is typically higher (and by extension so are the risk of treatment failure and the need for retreatment) because iodine uptake is lower than in Graves' disease.
• Third, SSKI and Lugol's solution are not indicated for toxic multinodular goitre as they are for Graves' disease, because the high iodine concentration may not produce a temporary euthyroid state by the Wolff-Chaikoff effect and instead induces hyperthyroidism through the Jod-Basedow phenomenon [1].
• For a solitary toxic adenoma the philosophy is the same: antithyroid drugs are not effective for long-term remission and either radioiodine or thyroidectomy is preferred for definitive treatment [1].
• Toxic nodular goitre is often large and enlarges further with antithyroid drugs, so large goitres are treated surgically as they respond less well to radioiodine or antithyroid drugs than diffuse toxic goitre does [4].

Thermal ablation has shown variable resolution of hyperthyroidism for toxic adenomas compared with surgery or radioiodine, so radiofrequency ablation is not recommended as first-line treatment for large toxic adenomas, though it can be considered in young patients with small ones. Nodules under 12 mL in volume with volume reduction exceeding 80% are more likely to see resolution of hyperthyroidism [1].

Medical treatment of amiodarone-induced thyrotoxicosis typically consists of methimazole, with corticosteroids added to address the thyroiditis in type 2 disease; the decision to stop amiodarone must be made individually with the treating cardiologist to ensure continuity of adequate antiarrhythmic therapy in these often high-risk patients [1]. Total thyroidectomy is recommended for patients unresponsive to aggressive medical therapy, and although thyroidectomy carries more risk in this setting than in most other indications, with perioperative mortality of 9% to 10%, delaying surgery carries an even higher risk of mortality [1].

Preoperative preparation

• Carbimazole 30–40 mg/day is given until euthyroid, taking 8–12 weeks, then reduced or converted to a 'block and replace' regimen of carbimazole plus 0.1–0.15 mg thyroxine daily.
• Alternatively β-adrenergic blockade can achieve clinical euthyroidism within days, but must be continued for 7 days post-operatively because hormone levels remain high.
• Iodine as Lugol's solution may be added for 10 days pre-operatively to reduce vascularity via the Wolff–Chaikoff effect [2][4].
• Sabiston notes that patients should ideally be rendered euthyroid before thyroidectomy with antithyroid medication, but that recent studies suggest the risk of thyroid storm during thyroidectomy in actively thyrotoxic patients is minimal [1].
• High-concentration potassium iodide solutions can be given for 7 to 10 days before surgery and are thought to decrease thyroid blood flow and gland vascularity while helping to achieve a euthyroid state rapidly, though their use may not be helpful or needed in selected situations.
• Cholestyramine or lithium can be repurposed to decrease circulating free thyroid hormone levels, and preoperative optimisation of calcium and vitamin D status, including calcitriol supplementation, has been shown to decrease the postoperative risk of transient hypocalcaemia [1].

Thyroid storm

• Thyroid storm is a rare state of life-threatening physiological decompensation in patients with severe uncontrolled hyperthyroidism, often after an inciting stressor; symptoms are dramatic and severe, and include fever, cardiac effects (hypertension, tachycardia, arrhythmia, congestive heart failure), mental status changes (agitation, stupor, coma), and hepatic failure [1].
• Treatment is multimodal, β-blockade, antithyroid medication, potassium iodide, corticosteroids, mechanical cooling and intensive supportive care, with plasmapheresis reported to reduce circulating hormone rapidly and worth considering in severe cases, though limited by cost and availability [1].
• Beta-blockers are the first drug given; Lugol's solution or potassium iodide is most effective through the Wolff–Chaikoff effect but slow to act; cooling blankets, oxygen and glucose are added; high-output cardiac failure is the most common cause of death, and emergent thyroidectomy is rarely indicated [2].

Doses, relapse and the selection rules in Schwartz's account

• Propylthiouracil is given 100–300 mg three times daily and methimazole 10–30 mg three times daily then once daily; methimazole's association with congenital aplasia makes PTU preferred in pregnancy and breastfeeding, agranulocytosis is treated by admission, drug withdrawal and broad-spectrum antibiotics with surgery postponed until the granulocyte count reaches 1000 cells/mm³, most patients improve within 2 weeks and are euthyroid by about 6, and the block-replace regimen adds 0.05–0.10 mg T4 because some but not all studies show lower recurrence [7].
• Relapse after a 1–2-year course affects 40–80%, so curative-intent drug therapy is reserved for small non-toxic goitres under 40 g, mildly raised hormone levels, negative or low receptor-antibody titres and rapid shrinkage on treatment [7]. β-blockade is recommended for the elderly, those with cardiac disease and resting heart rates above 90 bpm, propranolol at about 20–40 mg four times daily (higher doses sometimes needed because clearance is increased), with calcium-channel blockers for rate control when β-blockers are contraindicated [7].
• RAI is given as 8–12 mCi orally after a preliminary scan once drugs have rendered the patient euthyroid and been stopped; most are euthyroid within 2 months but only about 50% at 6 months, hypothyroidism then accrues at about 2.5% a year, ophthalmopathy progresses in 33% after RAI against 16% after surgery, and small excesses of nodular goitre, thyroid cancer, hyperparathyroidism and unexplained overall and cardiovascular mortality are reported; absolute contraindications are pregnancy (or planned within 6 months) and breastfeeding, relative ones youth, nodules and ophthalmopathy, and lack of access to a high-volume surgeon also weighs [7].
• Surgery is recommended for confirmed or suspicious nodules, the young, those wishing to conceive within 6 months, severe drug reactions, goitres over 80 g with compression and reluctance to have RAI, and relatively for moderate-to-severe ophthalmopathy especially in smokers, desire for rapid control and poor compliance; in pregnancy it is used only when rapid control is needed and drugs cannot be, best in the second trimester [7].
• Lugol's or saturated potassium iodide, three drops twice daily from 7–10 days before, acts mainly by inhibiting hormone release, and when euthyroidism cannot be achieved the patient is prepared with β-blockade and iodide alone, steroids being a useful adjunct [7].
• In storm, non-aspirin antipyretics are used, Lugol's iodine or intravenous sodium ipodate cuts iodine uptake and hormone secretion, PTU blocks new synthesis and peripheral conversion, and corticosteroids prevent adrenal exhaustion and block hepatic conversion [7].

Surgeries

• For diffuse toxic goitre and toxic nodular goitre with overactive internodular tissue, surgery cures by reducing thyroid mass below a critical level.
• Subtotal thyroidectomy returns the patient to euthyroid, after a variable hypothyroid period, but carries long-term recurrence and failure risk, whereas total or near-total thyroidectomy accepts immediate thyroid failure and lifelong thyroxine in exchange for eliminating recurrence risk and simplifying follow-up [4].
• Near-total or total thyroidectomy is associated with a nearly 0% risk of recurrent hyperthyroidism, against 5–10% recurrence after subtotal thyroidectomy from residual tissue, and is now generally preferred [1].
• Recurrence of thyrotoxicosis occurs in at least 5% of subtotal thyroidectomies, and there is a risk of permanent hypoparathyroidism and nerve injury [4].
• Near-total or total thyroidectomy is now preferred over subtotal thyroidectomy because of the lower recurrence rate, and surgery is preferred over radioactive iodine in childbearing women who wish to conceive in the near future, in non-compliant patients, and where airway obstruction appears likely [9].

Rates of permanent RLN injury (0–2%), permanent hypoparathyroidism (0.6–6%) and neck haematoma (0.3–0.7%) after total thyroidectomy in Graves' disease are higher than for other indications but remain low, especially with high-volume surgeons, and there is no difference in complication rates between total/near-total and subtotal thyroidectomy groups, which removes the last argument for accepting the recurrence risk of a subtotal resection [1]. The risk of complications from remedial repeat thyroidectomy is up to tenfold higher than initial surgery, which further underscores why subtotal thyroidectomy is no longer favoured [1].

• For an autonomous toxic nodule, or a toxic nodular goitre with overactive autonomous nodules, surgery cures by removing the overactive tissue and allowing the suppressed normal tissue to recover function; resection is easy and certain with limited morbidity [4].
• Thyroidectomy for a toxic adenoma is typically limited to unilateral lobectomy addressing the side of the adenoma, a strategy associated with near-universal cure of the hyperthyroidism; near-total or total thyroidectomy is indicated only where there are other factors, such as bilateral nodules with suspicion of cancer or a large or symptomatic goitre [1].
• Hemithyroidectomy may be considered for unilateral toxic nodules [3].
• Near-total or total thyroidectomy is likewise the generally recommended surgical treatment of toxic multinodular goitre, since complete extirpation carries a similarly low complication rate to subtotal thyroidectomy while virtually eliminating recurrence [1].

• The surgical technique for thyroidectomy involves a transverse cervical incision, subplatysmal flap elevation, division between strap muscles, identification of the RLN (often but not always posterior to the inferior thyroid artery, in about 70% of cases) and preservation of parathyroid blood supply, careful management of Berry's ligament, and delivery and division of the gland.
• Intraoperative nerve monitoring is increasingly used, particularly in reoperative cases [4].
• Full operative detail is set out on the Thyroid Nodules and Goitre page.

From subtotal to total thyroidectomy in Schwartz's account

Subtotal thyroidectomy leaving a 4–7 g remnant, bilaterally, or as a total lobectomy on one side with subtotal resection on the other (Hartley–Dunhill procedure, which theoretically has fewer complications and requires re-entering only one side at reoperation), was formerly standard, but recurrence depends on remnant size, total resection adds only temporary hypoparathyroidism, and ophthalmopathy stabilises or improves in most after total thyroidectomy, presumably from removal of the antigenic stimulus, so the revised ATA guidelines recommend total or near-total thyroidectomy as the procedure of choice, with recurrent thyrotoxicosis usually managed by radioiodine [7]. In toxic multinodular goitre near-total or total thyroidectomy is recommended to avoid re-operative complications, the recurrent laryngeal nerve may lie lateral on the gland or stretched anteriorly over a nodule, and RAI is reserved for elderly poor-risk patients without airway compression or cancer concern because uptake is lower (needing larger doses), RAI thyroiditis can swell the goitre and compromise the airway, and the goitre is left in situ; toxic adenoma is treated by lobectomy and isthmusectomy in the young and for larger nodules, smaller ones by drugs and RAI, and percutaneous ethanol injection has reasonable reported success but no direct comparison with surgery [7].

Complications

• Post-thyroidectomy stridor requires emergency wound opening and haematoma evacuation to prevent airway compromise; it can also result from bilateral RLN injury, requiring emergency tracheostomy [2].
• Permanent hypoparathyroidism and RLN injury are recognised risks of surgery for thyrotoxicosis, particularly after subtotal resection or reoperation [4].
• Graves' disease is an independent risk factor for postoperative hypoparathyroidism and for neck haematoma, and is one of the situations in which prophylactic preoperative calcitriol is given [1].
• Young women tend to have a poorer cosmetic result from the surgical scar [4].
• Thyroid storm itself is a life-threatening complication of undiagnosed or inadequately treated Graves' disease, most commonly precipitated by surgery, and carries risk of high-output cardiac failure and death if untreated [2][3].
• Radioiodine treatment risks include worsening of Graves' eye signs, quarantine requirements, avoidance of pregnancy and close contact with children afterwards, and a rate of secondary malignancy that emerging evidence suggests is higher than previously reported [1][3].

Prognosis

• Medical therapy for Graves' disease has a reported success rate of about 95% in managing hyperthyroidism, though recurrence after antithyroid drugs is around 50% and after radioiodine around 5% [2].
• Nearly one-third of patients may achieve long-term remission with antithyroid medication alone [1].
• It is unusual to need to operate on Graves' disease patients; a suspicious nodule is the most common reason for surgery [2].
• With suitable preoperative preparation and an experienced surgeon, operative mortality for thyrotoxicosis surgery is negligible and morbidity low [4].
• Untreated or unrecognised thyroid storm carries a high mortality rate, principally from high-output cardiac failure [2][3].
• Amiodarone-induced thyrotoxicosis is the exception to the generally excellent surgical outcomes: thyroidectomy in that setting carries a perioperative mortality of 9% to 10%, though delaying surgery in an unresponsive patient carries a higher risk still [1].
